Детайли
| Marketing Description | |
| The Cisco SF350-48 Switch is a forty-eight port, part of the Cisco Small Business line of network solutions, and portfolio of affordable managed switches that provides a reliable foundation for your business network. This switch delivers the features you need to improve the availability of your critical business applications, protect your sensitive information, and optimize your network bandwidth to deliver information and applications more effectively. Easy to set up and use, the Cisco SF350-48-K9-NA switch provides the ideal combination of affordability and capabilities for small businesses and helps you create a more efficient, better-connected workforce. | |
| Product Features | |
| |
| General | |
| Device Type | Switch - 48 ports - L3 - Managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Fast Ethernet |
| Ports | 48 x 10/100 + 2 x 10/100/1000 + 2 x combo Gigabit SFP |
| Performance | Switching capacity: 17.6 Gbps Forwarding performance (64-byte packet size): 13.1 Mpps |
| Capacity | Active VLANs: 4096 |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | Static IPv4 routing, CIDR |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI |
| Encryption Algorithm | SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | Layer 3 switching, Layer 2 switching, DHCP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, 12MB packet buffer |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az |
| RAM | 512 MB |
| Flash Memory | 256 MB |
| Status Indicators | Link/activity |
| Expansion / Connectivity | |
| Interfaces | 48 x 100Base-TX RJ-45 2 x 1000Base-T RJ-45/SFP 2 x 1000Base-T SFP 1 x console RJ-45 management 1 x USB management |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Cables Included | 1 x power cable 1 x console cable |
| MTBF | 277,653 hours |
| Compliant Standards | UL 60950, FCC Part 15 A, CSA 22.2 |
| Localisation | Europe |
| Dimensions & Weight | |
| Width | 44 cm |
| Depth | 25.7 cm |
| Height | 4.45 cm |
| Weight | 3.57 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day Technical support - web support - 1 year Technical support - phone consulting - 1 year |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 90% (non-condensing) |
Допълнителна информация
| Производител | CISCO |
|---|---|
| Тип | Fixed Port |
| VLAN | Port-based and 802.1Q tag-based VLANs; Support for up to 4096 VLANs simultaneously |
| Размер на таблица с MAC адреси | 16384 MAC address table size |
| Капацитет на трафик | 13.09 Mpps |
| Скорост на сериен трансфер на данните | 17.6 Gbps |
| Захранване | Internal power supply: 100-240V, 50-60 Hz |
| Брой портове | 52 |
| Характеристики за сигурност | SSH, SSL, IEEE 802.1X (Authenticator role), Web-based authentication, STP BPDU Guard, STP Root Guard, DHCP snooping, IP Source Guard, Dynamic ARP Inspection, IP/MAC/Port Binding, SCT, SSD, Port security, RADIUS/TACACS+, Storm control, DoS prevention, ACLs |
| Гаранционен срок (месеца) | 99 месеца |
