Детайли
Суич, тип Fixed Port
Общ брой портове 12
Основни портове, тип 10x10GBase-T
Uplink портове 2 dual personality
Управление Web interface; Management through SNMP; Remote firmware upgrade by Web; Configuration saving and retrieving; DHCP; NTP; SNMP v1, v2c, v3; SNMP trap group; RMON (1, 2, 3, 9); ICMP echo/echo reply; Syslog; IEEE 802.1AB LLDP; IEEE 802.1AB LLDP-MED
Stackable ZyXEL iStacking™
Fans Fanless design
Захранване Input voltage: 100 - 240 V AC, 50/60 Hz; Max. power consumption: 94.1 (watt)
Routing Layer 2 Only
Памет (Flash, RAM) -
Капацитет за маршрутизиране/превключване, Gbps 240 Gbps
Пропускателна способност, Mpps 178.6 Mpps
MAC адреси 16000 MAC address table size
VLAN (брой, стандарти) 802.1Q Static VLANs/Dynamic VLANs: 1 K/4 K; Port-based VLAN; Protocol-based VLAN; IP Subnet-based VLAN; MAC-based VLAN; Private VLAN; Voice VLAN; VLAN ingress fltering; GVRP; LACP algorithm of source/destination MAC/IP; L2PT
QoS 8 hardware queues per port; 802.1p queuing methods: SPQ, WRR, WFQ; Storm control: broadcast, multicast, unknown unicast (DLF); 802.1p Class of Service (SPQ, WFQ, SPQ/WFQ combination capable); DiffServ (DSCP); Rate limiting per IP/TCP/UDP per port
L2 мрежови стандарти IEEE 802.3ab, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3z, IEEE 802.3x flow control, IEEE 802.3az EEE support, IEEE 802.3ad LACP aggregation, IEEE 802.1AB, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X
L3 мрежови стандарти -
IPv6 functionality IPv6 over Ethernet, IPv6 addressing architecture, Dual stack, ICMPv6, Path MTU, Minimum path MTU size of 1280, Encapsulation for maximum PMTU of 1500, Neighbor discovery, DHCPv6 relay
Сигурност 802.1X, Port security, Layer 2 MAC filtering, Layer 3 IP filtering, RADIUS, TACACS+, SSL, MAC freeze, DHCP snooping, ARP inspection, Static IP-MAC-Port binding, Port isolation, IP source guard, ACL packet filtering (IPv4/IPv6), CPU protection
Размери, mm 440 x 330 x 44.5 mm, 19" rackmount
Допълнителна информация
Производител | ZYXEL |
---|---|
Захранване | 100 до 240V/AC, 50 до 60Hz |
Брой портове | 10x 1000/10GBASE-T; 2x 10Gb combo (SFP/RJ-45) |
Характеристики за сигурност | 802.1X, Port security; Layer 2 MAC filtering; Layer 3 IP filtering; TACACS+/RADIUS; SSH v1/v2; SSL; MAC freeze; DHCP snooping; ARP inspection; Static IP-MAC-Port binding; Port isolation; IP source guard; ACL packet filtering (IPv4/IPv6) |
Размери | 440 x 330 x 44.5 |
Гаранционен срок (месеца) | 60 |
